Introduction

The late 1930s marked a turning point in North American railroading. Steam locomotives, long the backbone of freight service, were increasingly outmatched by the demands of a modernizing economy and the pressures of wartime production. Enter the Electro-Motiv Division’s F-unit series—beginning with the FT in December 1939 and evolving through F3, F7, and beyond. These iconic cab-unit diesels not only triumphed over steam on efficiency and reliability but also set a standard of modular engineering that would influence locomotive design for decades.

• EMD 567 Powerplant
  At the heart of every F-unit sat the two-stroke, 45° V16 EMD 567 engine, rated at 1,350 horsepower. Its “567” designation referred to cubic inches per cylinder, a design that prioritized easy maintenance: power assemblies (cylinder, piston, rod) could be swapped in under an hour.

• Modular Carbody and Running Gear
  The carbody followed a modular philosophy: trucks, radiators, fuel tanks, and electrical assemblies bolted to a standardized frame. A-units (with cabs) and B-units (cabless boosters) shared identical power sections, reducing spare parts inventories.

• Electrical Systems
  DC generators (later alternators), robust traction motors, and optional dynamic braking gave railroads fine control over speed and tonnage. Early units featured straight air brakes; later F7s incorporated more sophisticated independent brake valves.

By 1941, many Class I railroads had phased out top-end steam power on mainlines. According to the 1940 Santa Fe timetable, the Chicago–Los Angeles “Chief” could sustain higher average speeds with F-units, shaving an hour off the schedule thanks to rapid acceleration and fewer water stops.

• Efficiency Gains
  Diesel units consumed roughly 1.5 lb of fuel per horsepower-hour versus steam’s 8–10 lb of coal equivalent. Maintenance intervals stretched to 50,000 miles between major overhauls.

• Wartime Reliability
  During WWII, the U.S. Army Transportation Corps ordered over 1,000 FTs and FTs-derived units. Their uninterrupted service hauling munitions and troops underscored diesel’s strategic advantage.

Steam locomotives required daily boiler washouts, tube replacements, and ash disposal. In contrast, F-units offered:

• Quick Overhauls
  A failed power assembly could be swapped in under an hour, minimizing downtime.

• Standardized Parts
  Across EMD’s product line, common components reduced lead times for spares.

• Crew Comfort
  Heated cabs, electric lighting, and smoother ride on Flexicoil trucks improved morale and safety.

The F-unit’s blend of streamlined carbody and plug-compatible internals became a template:

• EMD E-Units borrowed the 567 engine and carbody philosophy for passenger service.
• GP (General Purpose) Series adopted modular frames and trucks, leading to the universal hood units of the 1970s and ʼ80s.
• Modern Dash Series still echo the 567’s descendants in naming (e.g., 645, 710) and block-swap design.

For modelers, F-units remain a staple:

• Scales: HO, N, O gauge
• Liveries: Santa Fe Warbonnet, Union Pacific Armour Yellow, Pennsylvania Tuscan Red
• Aftermarket: LED lighting kits, DCC sound decoders replicating EMD 16-567 “chuff”

Collectors also prize mid-century conductor badges. EMD issued enamel pins between 1947–1952, featuring miniature F-unit motifs—today highly sought after on eBay and railiana shows.

Over 7,800 F-unit cab and booster units rolled out between 1939 and 1960. While most have long since been retired, their impact persists:

• Repowered “Geeps” still run daily on shortlines.
• Preservation fleets showcase restored F3s and F7s at museums like the Illinois Railway Museum.
• Their distinctive profile—slanted nose, long side skirts—remains emblematic of the diesel era.

Now departing for posterity!
Don your conductor badge, consult the 1959 Union Pacific timetable, and imagine that distinctive hum of the 567 engine pulling a heavy freight across the plains.

Whistles: 5/5
